My Bike


* 100 mm  Modern front hubs.
  126 mm  Rear 6- and 7-speed (road).
  130 mm  Rear 7-speed (MTB) and 8- 9- and 10-speed (road).
  135 mm  Rear 7- 8- and 9-speed (MTB)

  Most mountain bikes are 135mm but there are still some older
  130mm bikes around. In some cases it will be 132.5mm which can take
  either 130mm, or 135mm spaced hubs.

  6- and 7-speed hubs generally use 126 mm spacing, while 8-/9-speed hubs use
  130 mm (road) or 135 mm (MTB/Hybrid).

* 2.7cm post

  rear wheel
  bike frame

Back Derailleur

  RD-TX30 TOURNEY GS

  RD-TY15
  RD-TY22

  SRAM ESP 1:1 rear derailleurs only

  Shimano XTR Rear Deraillers

Front Derailleur

Clamp diameter 28.6 mm (1-1/8), 31.8 mm (1-1/4), and 34.9 mm (1-3/8).

Crankset

6.5 inches = 165 mm

$119 Truvativ Firex 3.3 Team GXP Crankset  44/32/22 chainrings

28/38/48

Bottom Bracket

Phil Wood Stainless Steel Spindle Bottom Bracket
Hope Titanium BB
Shimano UN 71/ 72 Bottom Bracket

          inches        mm
A         1.4            36
B         2.12           54
C         1.6            41
D         5.18          132
E         6.0           152

Housing   2.67           68

3A-B  32.0x52x33.0-117
3H-B  29.5x52x33.5-113
3RR-B 42.0x52x42.0-136
3T-B  32.0x52x39.0-123

3H    30.4x52x30.5-113      113
3K    32.0x52x33.5-117.5    119
3L    32.0x52x32.0-116
3N    32.0x52x36.0-120      124
3NN   36.0x52x36.0-124      124
3P    32.0x52x35.0-119      122
3S    35.0x52x37.5-124.5    127
3SS   32.0x52x37.5-121.5
3T    35.0x52x39.0-126      130 *
3U    35.0x52x30.5-127.5    133 *
3TR   42.0x52x39.0-133      130

Gears

  Freewheel
  Cassette

  Shimano XTR M970 Cassette M-970 9 Speed Titanium 12-34
  Shimano XTR CS-M970 Cassette

Brakes

  Direct-pull ("V-type") Cantilevers
  Link Fixing Bolt M6x22

Dia Compe Transverse (straddle cable)

Code	Length
S	 63 mm
A	 73 mm
B	 82 mm
C	106 mm
D	 93 mm

Brake Shoes

Mathauser brake shoes

Kool Stop Mountain Salmon

Kool Stop Supra 2

Cables

Shifters

  Shimano SL-TY22 Tourney SIS Shift Lever
  Shimano Stx/Alivio MC40 7 Speed                              $25
  Sram SX4 7 speed   SRAM Rear Derailleur    (1:1 Actuation)
  Sram TRX 7 speed   Shimano Rear Derailleur (1:2 Actuation)   $21

  Sram X.0
  Sram X.9
  Shimano XTR SL-M970 Rapidfire Levers

Hubs

Spacers

  Shimano Deore bad review
  Shimano XT    good review

Forks

Rims

  Mavic 517
  Sun Rhyno Lite
  DT Swiss
  Chris King

Wheels

  Shimano Deore M525 Disc/Sun Rhyno Lite Wheelset
  Shimano XT 756/Ta Rhynolite Wheelset                   $165
  Shimano Deore XT 770/Mavic 717/DT Swiss/840g           $140

Spokes

DT Swiss spokes

Tools

  4th hand
  Cone wrench
  Crank puller
  Chain ring wrench
  Cable cutter
  Floor pump

Misc

Rim tape

Price Compare

                                                  Performance   REI  Jensen  Chainreactioncycles   eBay
Shimano XTR FD-M971 Bottom Swing Front Derailleur      $99.99
Shimano XTR FD-M970 Top Swing Front Derailleur        $114.00
Shimano XTR RD-M970-SGS Rear Derailleur               $169.99
Shimano XTR CS-M970 Cassette                          $209.00  $239    $239                        $158
Shimano XTR SL-M970 Shifters                          $224.00  $229    $179   $135                 $152
Shimano XTR FC-M970 Crankset                          $499.99                 $347
Shimano XTR BL-M970 V-Brake Lever Set                                  $150
Shimano XTR M970 V-Brake                                               $100

Purchase

* Shimano Deore LX BR-M560                               $14
* Shimano BL-M420 V-Brake Levers
* Avid Single Digit 7 V-Brake

  Pyramid 6 speed SIS 14-28 tooth                        $11
  Pyramid 7 1/2 inch spoke protector                     $3
  Shimano XTR Gear cable 1.2x2100mm
  Shimano SL-TY22 (SIS Shifter levers)                   $8.32
  Chain Sram PC-870                                      $16
  Shimano Stx/Alivio MC40 7 Speed                        $25
  Shimano Deore XT 770/Mavic 717/DT Swiss/840g           $140
  Cable cutter                                           $27
  Quick release seat binder
  Tool bag
  Cone wrench   17/18
  Cone wrench   13/15
  Pedal wranch PW-3                                      $26
  * Pedal wrwnch PW-4                                    $25
  Pedal wrench PW-5                                      $7.95
  Crank and BB wrench HCW-4                              $14
  Ajustable spanner SPA-5
